8903 AZ
Temperature Anemometer
Features
AZ 8903 Handheld Wind Speed Meter features:
* Fashion design with one hand operation
* Integral fan with temperature sensor built-in
* Measures air velocity & temperature
* Wind speed metric and imperial units switchable
* Temp. Units C/F switchable
* Display max. / min. / avg. value
* Hold function to freeze current readings
* Auto power off in 20 mins inactivity to save power
* Sleep and non-sleep mode switchable
* LCD display flash as low battery indicator
Application
Application of 8903 AZ air flow measuring devices:
The 8903 AZ wind speed meter has the integral fan to measure the Air Speed, Air Velocity and Temperature. The meter features versatile functions, use it to check air velocity FPM (Feet per minute) in residential, light commercial and standard commercial systems.
The 8903 AZ Anemometer has many user-friendly features, all the features are accessible through the keypads. It could be the best choice as the wind speed monitoring device in HVAC (Heating, Ventilation, Refrigerating and Air Conditioning) or industrial related application.
The 8903 AZ Anemometer was being designed
and manufactured by AZ Instrument, a well experienced manufacturer for
Environmental Measuring Instrument.
Specification
Specification of 8903 Handheld Anemometer:
| Model | 8903 |
| Wind Speed Range | 0.4~30 m/s; 80~5900 ftm |
| Wind Speed Accuracy | ±(2% of reading+0.2 m/s) |
| Air Temperature Range | -10~50.0℃ |
| Air Temperature Resolution | 0.1℃, 0.1℉ |
| Air Temperature Accuracy | ±1℃ |
| Wind Speed Unit (m/s) | YES |
| Wind Speed Unit (ft/m) | YES |
| Temperature Response Time | 60 seconds (typical) |
| LCD Update | Every second |
| LCD Size | 40(L) * 34(W) mm |
| Operating Temperature | 0~50℃ |
| Operating RH% | Humidity ＜80% |
| Storage Temperature | -10~50℃ |
| Storage RH% | Humidity ＜90% |
| PC Link | YES |
| Battery Life | 100 Hours |
| Size | Meter: 183(L) * 76(W)* 45(H) mm Impeller: 70 mm |
| Weight | ~150g |
| Battery | 9V Battery *1 PC |
| Optional Accessory | Software Kit |
| Standard Package | Meter, Battery, Manual, Hard Carry Case |
